  • Carbon Steel 2-PC Ball Valve 3,600 psi (WOG)

Carbon Steel 2-PC Ball Valve 3,600 psi (WOG)

SKU: VBC3K

Manufacturer: DuraChoice

From: $49.72 to $314.34
  • VBC3K-025 1/4" NPT Carbon Steel 2-PC Ball Valve 3,600PSI
    Qty. $49.72
  • VBC3K-038 3/8" NPT Carbon Steel 2-PC Ball Valve 3,600PSI
    Qty. $50.68
  • VBC3K-050 1/2" NPT Carbon Steel 2-PC Ball Valve 3,600PSI
    Qty. $50.68
  • VBC3K-075 3/4" NPT Carbon Steel 2-PC Ball Valve 3,600PSI
    Qty. $59.34
  • VBC3K-100 1" NPT Carbon Steel 2-PC Ball Valve 3,600PSI
    Qty. $89.81
  • VBC3K-125 1-1/4" NPT Carbon Steel 2-PC Ball Valve 3,600PSI
    Qty. $118.68
  • VBC3K-150 1-1/2" Carbon Steel Full Port ball valve, NACE, RPTFE, Seal Welded, Oilfield, 316 Ball, 3,600PSI FxF NPT
    Qty. $163.59
  • VBC3K-200 2" Carbon Steel Full Port ball valve, NACE, RPTFE, Seal Welded, Oilfield, 316 Ball, 3,600PSI FxF NPT
    Qty. $314.34
Items:0  |  Total:$0.00

DESCRIPTION

High pressure valve with 3,600 psi rating. Two-piece, WCB carbon body, seal-welded to improve strength.

One of the best high pressure valves we sell. The VBC3K line is made with a 3600 psi rating for oilfield and petroleum industry use. Seal welded for additional strength and designed to resist corrosion in oil and natural gas production environments.

  • 2-piece body cast carbon steel full port design
  • Seal weld adds structural stability
  • Working pressure of 3600 psi (WOG)
  • Suitable for full range of liquids and gas
  • DELRIN seat
  • Pressure tested according to API598
  • 100% individually tested
  • Meets NACE MR0175 standard
  • ISO 9001 standard
  • NPT threaded ends
  • Heavy duty locking handle with insulator


Designation
Material

BodyWCB

BallSS 316

CapWCB

Ball SeatDELRIN

Thrust WasherRPTFE

StemSS 316

Gland NutA194 Gr. 8

Stem NutA194 Gr. 8

HandleSS 304

Handle NutA194 Gr.8

Handle LockSS 304

Handle CoverPlastic


Torque List

VBC3K-0258 N.M71 in-lb
VBC3K-0389 N.M80 in-lb
VBC3K-05011 N.M97 in-lb
VBC3K-07520 N.M177 in-lb
VBC3K-10023 N.M204 in-lb
VBC3K-12535 N.M310 in-lb
VBC3K-15044 N.M389 in-lb
VBC3K-20052 N.M460 in-lb
