  • Carbon Steel 2-PC Ball Valve 6,000 psi (WOG)

Carbon Steel 2-PC Ball Valve 6,000 psi (WOG)

SKU: VBC6K

Manufacturer: DuraChoice

From: $58.21 to $339.32
  • VBC6K-025 1/4" NPT Carbon Steel 2-PC Ball Valve 6,000PSI Low Stock - Chat or Call to check
    Qty. $58.21
  • VBC6K-038 3/8" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $58.21
  • VBC6K-050 1/2" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $58.21
  • VBC6K-075 3/4" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $70.45
  • VBC6K-100 1" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $98.07
  • VBC6K-125 1-1/4" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $133.65
  • VBC6K-150 1-1/2" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $186.75
  • VBC6K-200 2" NPT Carbon Steel 2-PC Ball Valve 6,000PSI
    Qty. $339.32
Items:0  |  Total:$0.00

DESCRIPTION

High pressure valve with 6,000 PSI rating. Two-piece, wrought carbon body, seal-welded to improve strength.
The VBC6K line is the strongest high pressure valve in the DuraChoice family. Rated at 6000 psi and formulated to resist corrosion caused by HS2 environments, the valve is perfect for oilfield and natural gas production.

  • 2-piece body wrought carbon full port design
  • Seal Welded for added structural stability
  • Working pressure of 6,000 psi (WOG)
  • Suitable for full range of liquids and gas
  • PEEK seat
  • Pressure tested according to API598
  • 100% individually tested
  • Meets NACE MR0175 standard
  • ISO 9001 standard
  • NPT threaded ends
  • Heavy duty locking handle with insulator


DesignationMaterial

BodyWCB

BallSS 316

CapWCB

Ball SeatPEEK

Thrust WasherRPTFE

StemSS 316

Gland NutA194 Gr. 8

Stem NutA194 Gr. 8

HandleSS 304

Handle NutA194 Gr.8

Handle LockSS 304

Handle CoverPlastic


Torque List

VBC6K-02518 N.M159 in-lb
VBC6K-03820 N.M 177 in-lb
VBC6K-05021 N.M186 in-lb
VBC6K-07532 N.M283 in-lb
VBC6K-10040 N.M354 in-lb
VBC6K-12550 N.M442 in-lb
VBC6K-15055 N.M487 in-lb
VBC6K-200100 N.M885 in-lb
