Brass Gate Valve - 200 PSI (WOG)


Brass forged body with a cast iron handle
Working pressure of 200 PSI (WOG); 125 WSP
Non-rising stem
Suitable for full range of liquids and gas
Flow can go in either direction
Working temperature of 0-300 Degrees F
Each valve individually tested
NPT Threaded ends (ANSI B1.20.1)

Brass Gate Valve - FxF, 200 PSI (WOG)

SKU: VGB01

Manufacturer: DuraChoice

From: $10.94 to $181.34
  • VGB01-025 1/4" Brass Gate Valve - 200WOG, FxF NPT
    Qty. $10.94
  • VGB01-038 3/8" Brass Gate Valve - 200WOG, FxF NPT Low Stock - Chat or Call to check
    Qty. $10.94
  • VGB01-050 1/2" Brass Gate Valve - 200WOG, FxF NPT
    Qty. $10.94
  • VGB01-075 3/4" Brass Gate Valve - 200WOG, FxF NPT Low Stock - Chat or Call to check
    Qty. $10.94
  • VGB01-100 1" Brass Gate Valve - 200WOG, FxF NPT Low Stock - Chat or Call to check
    Qty. $15.20
  • VGB01-125 1-1/4" Brass Gate Valve - 200WOG, FxF NPT Low Stock - Chat or Call to check
    Qty. $28.67
  • VGB01-150 1-1/2" Brass Gate Valve - 200WOG, FxF NPT
    Qty. $24.87
  • VGB01-200 2" Brass Gate Valve - 200WOG, FxF NPT Low Stock - Chat or Call to check
    Qty. $42.84
  • VGB01-250 2-1/2" Brass Gate Valve - 200WOG, FxF NPT Low Stock - Chat or Call to check
    Qty. $94.69
  • VGB01-300 3" Brass Gate Valve - 200WOG, FxF NPT
    Qty. $114.82
  • VGB01-400 4" Brass Gate Valve - 200WOG, FxF NPT
    Qty. $181.34
Items:0  |  Total:$0.00

DESCRIPTION

Gate Valves, also known as sluice valves, can regulate flow of a liquid or gas by turning the stem to raise or lower a gate inside the valve. Unlike ball valves, gate valves can be opened incrementally.


The DuraChoice line of gate valves features a non-rising stem for use in limited space. The valve is rated at 200 PSI.


Brass forged body with a cast iron handle
Working pressure of 200 PSI; 125 WSP
Non-rising stem
Suitable for full range of liquids and gas (WOG)
Flow can go in either direction
Working temperature of 0-300°F
Each valve individually tested
FxF NPT Threaded ends (ANSI B1.20.1)

Designation - Material
Body - Brass
Bonnet - Forged brass
Stem - Brass
Stop Ring - Brass
Packing - NBR
Hand Wheel Nut - SS 41
Hand Wheel - Cast iron
Packing Nut - Brass
Ring - Brass
Lock Nut - Brass
Disc - Brass




Please Note: Brass components in this product contain lead, known to the State of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers.



California Prop 65 Warning: Brass components in this product contain lead, known to the state of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers.
