Stainless Steel 316 Swing Check Valve - 200 PSI (WOG)

SKU: VCS01

Manufacturer: DuraChoice

1 Review
From: $26.45 to $123.77
  • VCS01-050 1/2" Stainless Steel (316) Swing Check Valve - 200WOG
    Qty. $26.45
  • VCS01-075 3/4" Stainless Steel (316) Swing Check Valve - 200WOG
    Qty. $34.97
  • VCS01-100 1" Stainless Steel (316) Swing Check Valve - 200WOG
    Qty. $46.11
  • VCS01-125 1-1/4" Stainless Steel (316) Swing Check Valve - 200WOG
    Qty. $64.06
  • VCS01-150 1-1/2" Stainless Steel (316) Swing Check Valve - 200WOG
    Qty. $87.30
  • VCS01-200 2" Stainless Steel (316) Swing Check Valve - 200WOG
    Qty. $123.77
  • VCS01-025 Stainless Steel 316 Swing Check Valve - 200 PSI (WOG) Low Stock - Chat or Call to check
    Qty. $26.45
  • VCS01-038 Stainless Steel 316 Swing Check Valve - 200 PSI (WOG) Low Stock - Chat or Call to check
    Qty. $26.45
Items:0  |  Total:$0.00

DESCRIPTION

Stainless Steel (316) Swing Check Valve - 200 psi (WOG)
Stainless Steel Swing Check Valves (also known as tilt disc valves) are great for backflow prevention. A disc suspended at the top of the valve allows water to flow only one way with minimal force (1/2 lb. cracking pressure), while blocking attempts to flow in the opposite direction.


The DuraChoice line of stainless steel swing check valves is made of stainless steel 316 and has a working pressure of 200 PSI.


SS 316 investment casting body
Working pressure of 200 PSI
Suitable for full range of liquids and gas (WOG)
Temperature range: -40°F to 400°F
100% individually tested
NPT threaded ends to ANSI B1.20.1


Designation - Material
Body - SS 316/ CF8M
Bonnet - SS 316 (CF8M)
Disc - SS 316 (CF8M)
Hanger Pin - SS 304
Plug - SS 304
Plug Gasket - PTFE
Gasket - PTFE
