2-1/2" Oil-Filled Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection

SKU: PBG254B

Manufacturer: DuraChoice

1 Review
From: $9.40 to $11.46
  • PBG254B-030 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-30PSI GSSG2502-030UPD
    Qty. $9.40
  • PBG254B-060 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-60PSI GSSG2502-060UPD
    Qty. $9.40
  • PBG254B-100 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-100PSI GSSG2502-100UPD
    Qty. $9.40
  • PBG254B-160 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-160PSI GSSG2502-160UPD
    Qty. $9.40
  • PBG254B-200 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-200PSI GSSG2502-200UPD
    Qty. $9.40
  • PBG254B-300 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount, 0-300PSI GSSG2502-300UPD
    Qty. $9.40
  • PBG254B-600 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-600PSI GSSG2502-600UPD
    Qty. $9.40
  • PBG254B-K01 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-1,000PSI GSSG2502-1K
    Qty. $9.40
  • PBG254B-K02 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-2,000PSI GSSG2502-2KUPD
    Qty. $9.40
  • PBG254B-K03 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-3,000PSI GSSG2502-3KUPD
    Qty. $9.40
  • PBG254B-K05 2-1/2" Oil Pressure Gauge - Stainless Steel Case, Brass, 1/4" NPT Center Back Mount Connection, 0-5,000PSI GSSG2502-5KUPD
    Qty. $9.40
  • PBG254B-K06 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-6,000PSI GSSG2502-6KUPD
    Qty. $9.40
  • PBG254B-K10 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection, 0-10,000PSI GSSG2502-10KUPD
    Qty. $11.46
  • PBG254B-400 2-1/2" Oil Pressure Gauge - Stainless Steel Face, Brass, 1/4" NPT Center Back Mount Connection
    Qty. $9.40
Items:0  |  Total:$0.00

DESCRIPTION

Enjoy the same quality DuraChoice 2" liquid filled pressure gauges without any branding. These gauges offer outstanding performance in adverse conditions thanks to a stainless steel case with a brass connection, bourdon tube and movement.


Liquid filling helps protect against vibration and pulsation. They are available in pressure ranges from vacuum to 15000 PSI.


Dial Size: 1-1/2", 2", 2-1/2" or 4" Dial Sizes (Crimped Casing)
Accuracy: +/- 3/2/3%
Scale: Dual Scale - PSI/Bar
Movement: Copper Alloy*
Bourdon Tube: Copper Alloy*
Window: Polycarbonate
Case: Stainless Steel case for protection in harsh environments
Connection: Copper Alloy Center Back Mount*; 1/8" NPT for 1-1/2" dial, 1/4" NPT for 2" and 2-1/2" dials, and 1/4" NPT, 3/8" NPT, or 1/2" NPT for 4" dials
Normal Ambient Temp: -4 to +140 Degrees F (-20 to +60 Degrees C)

Please Note: Brass components in this product contain lead, known to the State of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers.
California Prop 65 Warning: Brass components in this product contain lead, known to the state of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers.
